AUTOOL SDT208 Car Smoke Leak Detector EVAP System Tester—an marvelously professional auto pipes Leak Smoke Tester, in line with the technical specifications of the car repair shop EVAP test. SDT208 greatly increases efficiency and helps us locate leaks from cars and motorcycles on our piping system within minutes, quickly and exactly, such as EVAP System Test、Intake System Test、Exhaust Systems Test， Turbo System Testing, Crankcase system test，Car Sealing Test, Various Pipe Fittings Test.
How to do leakage test？
1. Fill 10ml baby oil to the detector for the first time. Open the engine cover, and hang the detector in the cover.
2. Open the pipe that needs to be connected to the detector and access the adapter.
3. Connect detector with DC12V battery, turn on the power switch, and the detector starts to work
4. In about 30s, the pipe will be filled with smoke. Check the leak points. Please use head lamp if necessary.
AUTOOL SDT 208 Car Smoke Leak Detector Features：
[ Professional EVAP Detection ]： In line with the technical requirements of the car repair shop EVAP test. The SDT208 can detect tiny leak holes up to 0.5mm and has a hold-limit pressure protection function in
EVAP mode, so as to protect vehicle pipes from damages.
1. Standard Mode and EVAP Mode can NOT be turned on at the same time.
2. When you use this AUTOOL SDT208 Car Smoke Leak Detector EVAP System Tester for the first time, fill with 10ml oil . Please be careful NOT to beyond this range.
3. The testing liquid : both liquid paraffin and baby oil are OK.
4. Fresh oil can be filled with only when the smoke gets thin, and it can’t be filled over 20ml each time.
5. Before filling fresh oil, please pour out the left oil in the detector & replace the detector oil regularly.
6. During the process of leak detection, please keep away from smoke-sensitive parts.
7. Do NOT run the detector over 8 minutes continuously. It needs interval rest.
8.The detector has a smart protector,during operation, if the equipment senses the temp. above 75°C, the power supply will be automatically power off.
9. The round part of this detector has temperature, please be careful to avoid burns.
10. If the test pipe needs to be disconnected in the middle, please secure the other side with a rubber stopple.
1pcs * AUTOOL SDT208 Car Smoke Leak Detector EVAP System Tester Main Unit
1pcs * Rubber Connect Parts
1sets * Hard Rubber Hose Plug (with serial specification)
1sets * Soft Rubber Hose Plug (with serial specification)
1pcs * Standard Cone Adapter
1pcs * Universal Airbag Adapter
1pcs * Power Cord Clamp
1pcs * Valve Core Wrench
1pcs * Test Oil Refill Bottle(oil not included)
1pcs * EVAP Special Connector
1pcs * Smoke Hose
1pcs * User Manual
