Smoke Machine Leak Detector SDT Series Instruction Manual

Are you still struggling to find the right tools to use when draining a leak in your car system? With the industrial evolution of life there are more and more instruments for testing automobiles. The iteration of automotive leak testing tools has also entered a period of high speed, are you still using the traditional car vacuum leak tester? This article will tell you more about the process of using an automotive smoke leak detector and how to fix problems with the machine.

1. Scope of application of Car Smoke Test

The automotive smoke leak tester consists primarily of a smoke generator, smoke test liquid, smoke conduit, inlet adapter, plug kit, and other components. The smoke generator injects a certain amount of smoke into the tested automotive system through the conduit and air inlet, and determines whether there is a vacuum leak in the system and its location by observing the position where the smoke emerges.

2. What problems can the Smoke Machine Leak Detector solve?

The Automotive Smoke Leak Detector Tester is suitable for most of the vehicles with suspected leakage. Such as: intake/exhaust system, vacuum system, automotive evap system and fuel supply system. In addition, it can also be used in daily life for pipe leakages and similar situations.

3. SDT206 as an example of the use of automotive smoke machine process and precautions

Step 1: Please use liquid paraffin or baby oil instead, add no more than 10ml each time. If there is already oil in it. please do not continue to add. Adding too much oil will lead to no other space in the device to produce smoke.
Step 2: Connect the 12V battery by attaching the black clip to the negative terminal and the red clip to the positive terminal to ensure a 12V output.
Step 3: Connect the pipe to the adapter and ensure the pipe to be tested is completely sealed with the adapter.
Step 4: Switch on the power, check for leaks, adjust the smoke volume and recycle the remaining test oil after use.

4.Recommended for everyone AUTOOL best smoke test machine

Our advantages:

fast smoke output, 5-10s can produce smoke
overheating protection device, the machine will automatically stop working to protect the safety of the machine and the user.
old oil recycling treatment, save resources, environmental protection use, avoid accumulation.
The design features a high-quality appearance and a portable hook that boosts maintenance efficiency by attaching to the engine cover.
Built-in air pump, no need for external air compressor (except SDT101/103), integrated to save space.

5. Conclusion

Thank you for watching and I hope this article solved your doubts. Feel free to ask questions and leave your comments in the comment section about any car repairs and You can also contact me via official email or WhatsAPP.
