Automotive Endoscope Camera-Important Tool

With the rapid development of automotive endoscope cameras, the role and importance of endoscope cameras in automobile maintenance have become increasingly prominent. How many do you know about it?
This article will discuss the application and importance of automotive endoscope cameras in automobile maintenance.

What is an automotive endoscope camera?

An automotive endoscope camera, or industrial borescope or camera, is a tool used to inspect and visualize enclosed or hard-to-reach areas. It usually consists of a flexible or rigid tubular probe with a camera and light at the end, capable of transmitting images to an external display or monitor.
When automotive endoscope cameras are used in automotive repair and maintenance, they can help automotive repairers inspect the interior of engines, drivetrains, fuel systems, and other components in areas that are difficult to access with repair equipment, and then make accurate diagnoses of malfunctions and damage.

Why do you need to use an articulating borescope?

Carbon deposits are gels that build up on engine components such as engine valves, intake manifolds, and injectors. When the engine is in operation, certain components in the gasoline will condense to form a gelatinous carbon, and the condensed gelatinous carbon will continue to accumulate, thus affecting the normal operation of the sophisticated engine management system.

The diagnosis of carbon buildup on the intake pipe is very simple in automotive repair, as long as the throttle is removed, you can see the extent of carbon buildup. However, the diagnosis of valve carbon buildup has always been a difficult task, and generally speaking, professionals will provide two diagnostic methods.

① Disassembly method

The dismantling method is to take the engine apart and check for carbon deposits. This is very intuitive but time-consuming and labor-intensive, and no matter what parts are disassembled every time will more or less affect its performance and reduce its service life.

② Articulating borescope

Remove the spark plugs or injectors and use an automotive endoscope camera to observe the extent of carbon buildup on the valves. After completing the observation, gently withdraw the automotive endoscope camera from the inspection area to ensure that it does not damage any parts or affect the vehicle’s operation. Using an automotive endoscope camera not only improves the efficiency and accuracy of the inspection but also reduces the risk of damage that may be caused by the disassembly of parts, which is of great significance in safeguarding the safety, reliability, and long-term service life of automobiles.

Click to jump to the store to buy the AUTOOL automotive endoscope camera!

Operation steps:

1. Insert the automotive endoscope camera: Gently insert the lens of the endoscope camera into the part to be inspected, such as under the hood, exhaust pipe, brake system, electrical connector, etc. Make sure to insert it gently to avoid damaging internal parts or surfaces.
2. Observing and adjusting the angle of view: Observe the interior through the lens of the automotive endoscope camera. The viewing angle can be changed by rotating the lens or adjusting the bendable part at the end of the lens for better observation of the target area.
3. Illumination and Clarity Adjustment: Adjust the automotive endoscope camera’s LED lighting or other illumination as needed to ensure that details of the target area can be seen. Some automotive endoscope cameras may have the option to adjust the intensity of the illumination.
4. Take photos or video (optional): If you need to document the results of your examination or share them with others, you can use the photo or video function on the automotive endoscope camera to take pictures. Make sure that operating the camera function does not interfere with the examination.
5. Pay attention to safety and maintenance: During operation, pay attention to safety to avoid the cable of the automotive endoscope camera being pinched or pulled to avoid damaging the equipment. After the inspection, carefully put away and store the automotive endoscope camera to ensure that the equipment is clean and properly stored.

Application of automotive endoscope camera in automobile maintenance

• Engine Inspection

  The engine is the core component of the automobile, and whether its internal structure is intact or not is directly related to the performance and life of the automobile. Industrial endoscopes can be used to detect carbon, wear and tear, cracks, and other problems inside the engine to help maintenance personnel accurately locate fault points and improve maintenance efficiency.

• Fuel System Inspection

  The working condition of the fuel system directly affects the fuel consumption and power output of the car. Automotive endoscope cameras can be used to detect blockage, and wear and tear of fuel injectors, fuel lines, and other components, providing detailed fault information for maintenance personnel.

• Cooling System Inspection

  The function of the cooling system is to maintain the normal working temperature of the engine. An automotive endoscope camera can be used to detect scale, corrosion, and other problems in the cooling system to help maintenance personnel find and deal with potential safety hazards in time.

• Air-conditioning system detection

  The working condition of the air conditioning system directly affects the comfort of passengers. The automotive endoscope camera can be used to detect dirt and damage to the evaporator, condenser, and other parts of the air conditioning system, providing accurate maintenance programs for maintenance personnel.

• Brake System Inspection

  With the increase in the use of automobiles, various parts in the brake system may be worn, aged, or damaged, leading to a decline in braking performance and even safety problems. Therefore, regular testing and maintenance of the brake system is essential.

The importance of automotive endoscope cameras in maintenance

• Improving maintenance efficiency

  Traditional automobile maintenance methods often require the dismantling of a large number of parts to be detected, which is not only time-consuming and labor-intensive but may also cause secondary damage to the vehicle. The automotive endoscope camera can be used to directly test the interior of the vehicle without disassembling the parts, which greatly improves maintenance efficiency.

• Reduce misjudgment and omission

  The high-resolution image provided by the automotive endoscope camera enables maintenance personnel to accurately identify the subtle defects inside the vehicle, reducing the possibility of misjudgment and omission, and improving the quality of maintenance.

• Reducing Repair Costs

  Nondestructive testing through automotive endoscope cameras can avoid unnecessary disassembly and replacement of parts, thus reducing maintenance costs. At the same time, accurate fault diagnosis also helps to reduce the return rate, further reducing maintenance costs.

• Improved safety

  Automotive endoscope cameras can be tested without destroying the structure of the vehicle, avoiding the potential safety hazards that may be caused by the disassembly of components. In addition, timely detection and treatment of potential problems inside the car also helps to improve the safety of the car.

To summarize, Automotive endoscope cameras play an important role in automobile maintenance and have a wide range of application prospects. With the progress of science and technology and the continuous development of industrial endoscope technology, its application in the field of automobile maintenance will be more in-depth and extensive. Therefore, for automobile maintenance personnel, mastering the use of industrial endoscope technology will become a necessary skill.
